423.9×318 mm HV208QX1-100 Industrial LCD Displays HYDIS 20.8 inch for Medical Display

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

423.9×318 mm HV208QX1-100 Industrial LCD Displays HYDIS 20.8 inch for Medical Display

Brand Name : HYDIS

Model Number : HV208QX1-100

Certification : ISO9001

Place of Origin : KOREA

MOQ : 1 Piece

Payment Terms : T/T, Paypal, Western Union, MoneyGram

Supply Ability : 100 PCS / DAY

Delivery Time : 2-3 working days after payment confirmation

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Size : 20.8 inch

Resolution : 2048(LCR)×1536 , QXGA

Display Mode : AFFS, Normally Black, Transmissive

Signal Interface : LVDS (4 ch, 8-bit) , 70 pins

Contact Now

423.9×318 mm HV208QX1-100 Industrial LCD Displays HYDIS 20.8 inch for Medical Display

Our Advantages

  • We can be your professional Agent & Sourcing Line for the Hard-to-find LCD screen replacements.
  • 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.
  • Welcome small, medium & big quantity orders.
  • 100% QC Inspection before Shipment.
  • After-sales-service With 12 Months Warranty for our LCD panels.
Products Information:

Panel Size : 20.8 inch
Dot Resolution : 2048(LCR)×1536 (QXGA)
Pixel Configuration : LCR Vertical Stripe
Pixel Density : 122 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.069×0.207 mm (H×V)
Pixel Pitch : 0.207×0.207 mm (H×V)
Weight : 2.50Kgs  (Typ.)
Surface :
Antiglare (Haze 13%), Hard coating (3H)
Active Area : 423.9×318 mm (H×V)
Bezel Area : 428.0×322.0 mm (H×V)
Outline Dimension : 457×350 mm (H×V)
Outline Depth : 45.0 (Typ.) mm
Holes & Brackets : Side mounting holes (8 pcs)
Landscape or Portrait : Landscape type
Touch Panel : Without



Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
HX7308BTJFA Himax 0.45" 1024×768
HX7027ATGFA Himax 0.44" 640×480
HX7019ATGFA Himax 0.38" 640×360



Display Mode :
AFFS, Normally Black, Transmissive
Brightness : 800 cd/m² (Typ.)
Contrast Ratio : 700 : 1 (Typ.) (Transmissive)
Display Color : Grayscale (8-bit)
Response Time : 15/20 (Typ.)(Tr/Td)
Viewing Angle : 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.294; Wy:0.295
White Variation :
1.25 (Max.)(9 points)
Sunlight Readable : Y



N&S Delivery Details:
1) We are shipping this item to worldwide.
2) Our LCD panel orders processed within 1-3 working days of payment verification.
3) If you have not received the item on the Delivery Time. Please contact us. We will track the shipment and get back to your as soon as possible with a reply. Our goal is customer satisfaction.
5) We use the professional & safe package for our LCD screen replacements for you: Antistatic bag, Bubble Bag, Foam Box and Carton Box.

6) We will keep you updated for the Tracking NO. after we ship out the parcel to you.

7) Feel free to contact to us if there is any problems during the shipment process.



HV208QX1-100 Picture



423.9×318 mm HV208QX1-100 Industrial LCD Displays HYDIS 20.8 inch for Medical Display
