HSD190MEN3-A03 Industrial LCD Displays HannStar 19.0 inch with 376.32×301.056 mm

N&S ELECTRONIC CO., LIMITED
Contact Now

HSD190MEN3-A03 Industrial LCD Displays HannStar 19.0 inch with 376.32×301.056 mm

Brand Name : HannStar

Model Number : HSD190MEN3-A03

Certification : ISO9001

Place of Origin : KOREA

MOQ : 1 Piece

Payment Terms : T/T, Paypal, Western Union, MoneyGram

Supply Ability : 100 PCS / DAY

Delivery Time : 2-3 working days after payment confirmation

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Size : 19.0 inch

Resolution : 1280(RGB)×1024 , SXGA

Display Mode : TN, Normally White, Transmissive

Signal Interface : LVDS (2 ch, 8-bit) , 30 pins

Contact Now

HSD190MEN3-A03 Industrial LCD Displays HannStar 19.0 inch with 376.32×301.056 mm

Products Information:

Panel Size : 19.0 inch
Dot Resolution : 1280(RGB)×1024 (SXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 86 PPI
Aspect Ratio : 5:4 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.098×0.294 mm (H×V)
Pixel Pitch : 0.294×0.294 mm (H×V)
Weight :
1.95Kgs (Typ.)
Surface : Antiglare, Hard coating (3H)
Active Area : 376.32×301.056 mm (H×V)
Bezel Area : 380.2×305.0 mm (H×V)
Outline Dimension : 396×324 mm (H×V)
Outline Depth : 15.5/17.0 (Typ./Max.) mm
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without



Display Mode :
TN, Normally White, Transmissive
Brightness : 300 cd/m² (Typ.)
Contrast Ratio : 1000 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (6-bit + Hi-FRC)
Response Time : 1.2/3.8 (Typ.)(Tr/Td)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
White color Chromaticity :
Wx:0.313; Wy:0.329
White Variation : 1.33 (Max.)(9 points)
Sunlight Readable : N



Our services
1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4.Apart from the Indoor LED Display, Visionled also can offer you LED Pharmacy Cross Display, LED Flexible Display, Outdoor LED Display, LED Gas Price Signs, Indoor/outdoor LED Signs.



Packaging & Shipping:

Delivery Information:
Our professional testing team will test the LCD panels pcs by pcs, to make sure the LCD screen sent out are with good quality.
Shipping Method:
By Express: FedEx, DHL, EMS, TNT, UPS,
By Logistics: By air
Shipping Time:
From Monday to Saturday 8:00am-17:30pm
Shipping Address:
If by T/T, shipping address as communicate.



Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
HSD043B8W2-C01 HannStar 4.3" 480×800
HSD070IDW3-A00-0299 HannStar 7.0" 800×480
HSD050F9W1-A00 HannStar 5.0" 480×272
HSD050FDW1-A00 HannStar 5.0" 800×480
HSD043F9W1-A00 HannStar 4.3" 480×272
HSD050B8W4-A00 HannStar 5.0" 480×854

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk



HSD190MEN3-A03 Picture
