CLAA062LA01CW CPT 16 (Typ.)(Tr+Td) Response Time Antiglare Surface

  • 1
  • 2
  • 3

Brand Name : CPT

Model Number : CLAA062LA01CW

Certification : ISO9001

Place of Origin : China,Taiwan

MOQ : 1 piece

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Supply Ability : 100 PCS PER DAY

Delivery Time : 1-3 Working Days

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Aspect Ratio : 16:9 (H:V)

Active Area : 137.52×77.323 mm (H×V)

Outline Depth : 5.0±0.3 mm

Resolution : 800(RGB)×480 , WVGA

Panel Model : CLAA062LA01CW

Input Voltage : 3.3/9.2/18/-6.0/-4.0V (Typ.)(DVDD/AVDD/VDDG/VEEG/VCOM)

Contact Now

CLAA062LA01CW CPT 16 (Typ.)(Tr+Td) Response Time 16:9 (H:V) Aspect Ratio Antiglare Surface

Features and Advantages :
1. New and Industrial A grade perfect panels with stable supply
2. industrial control board supports the displays working 24 hours
3. Professional and industrial hardware and parts to guarantee its working normally in rough environment, Aluminum Front Bezel with rugged housing
4. Industrial design to protect the LCD screen, mounting on the outdoor application
5. VGA DVI interfaces
Mechanical Features :


Panel Size :6.2 inch
Dot Resolution :800(RGB)×480 (WVGA)
Pixel Configuration :RGB Vertical Stripe
Pixel Density :150 PPI
Aspect Ratio :16:9 (H:V)
Form Factor :Flat Rectangle Display
Dot Pitch :0.0573×0.1609 mm (H×V)
Pixel Pitch :0.1719×0.1609 mm (H×V)
Weight :115g (Typ.)
Surface :Antiglare
Active Area :137.52×77.323 mm (H×V)
Bezel Area :140.7×80.4 mm (H×V)
Outline Dimension :155.2×88.2 mm (H×V)
Outline Depth :5.0±0.3 mm
Landscape or Portrait :Landscape type
Touch Panel :Without



CPT CLAA062LA01CW Backlight System :
1. Lamp Position :Edge light type
2. Lamp Type : WLED
3. Lamp Amount : 3S6P
4. Lamp Shape : Array
5. Lamp Life Time : 30K(Min.) (Hours)
6. Lamp Voltage : 9.6±1.05V
7. Lamp Current : 120mA (Typ.)
8. Lamps Power Consumption : 1.17/1.3W (Typ./Max.)
9. Interface Type : Connector

Below are our other LCD panels stock for your easy reference:

Panel ModelBrandSizeResolution
CLAG024G401 AXCPT2.4"240×320
CLAG032HA01A0CPT3.2"320×480
CLAG030JB01A0CPT3.0"240×400
CLAG028GE21A0CPT2.8"240×320
CLAD035HA01 00XACPT3.5"320×480
CLAD032JA01X0CPT3.2"240×400

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

N&S Competitive Advantage:
We are a leading manufacturer of LCD products for more than 10 years.
We got the ISO9001 quality management system certification.
We have our own R&D team, and accept OEM order as per customer’s design.
We are the 5-years four star member of Globalsources and the Three year Gold supplier in Alibaba.
Our main material LCD panels all are directly imported from Samsung and LG in Korea. All products win the certificate of CE,CCC,FCC and RoHS.
Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 5 days.3-years warranty is offered.

Picture for CPT CLAA062LA01CW:

CLAA062LA01CW CPT 16 (Typ.)(Tr+Td) Response Time Antiglare Surface
 CLAA062LA01CW CPT 16 (Typ.)(Tr+Td) Response Time Antiglare Surface
CLAA062LA01CW CPT 16 (Typ.)(Tr+Td) Response Time Antiglare Surface
