Flat Rectangle 6.5 Inch NEC LCD Panel NL6448BC20-18D For Advertising Application
Quick Details:
<
| Panel Brand : | NEC |
| Panel Type : | a-Si TFT-LCD , Panel |
| Resolution : | 640(RGB)×480 , VGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 132.48×99.36 mm |
| Outline : | 153×118 mm |
| Surface : | Antiglare, Hard coating (2H) |
| Brightness : | 400 cd/m² (Typ.) |
| Contrast Ratio : | 600:1 (Typ.) |
| Display Colors : | 262K (6-bit) , CIE1931 40% |
| Response Time : | 6/19 (Typ.)(Tr/Td) |
| Viewing Angle : | 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 2 pcs CCFL Without Driver |
| Signal Interface : | CMOS (1 ch, 6-bit) , 31 pins |
| Input Voltage : | 3.3/5.0V (Typ.)(VCC) |
Technical Specifications for NEC NL6448BC20-08D LCD Panel:
<
| Display Mode : | TN, Normally White, Transmissive |
| Brightness : | 300 cd/m² (Typ.) |
| Contrast Ratio : | 250 : 1 (Typ.) (Transmissive) |
| Display Color : | 262K (6-bit) |
| Color Gamut : | 42% NTSC (CIE1931) |
| Response Time : | 13/36 (Typ.)(Tr/Td) |
| Viewing Angle : | 50/50/35/45 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | 6 o'clock |
| White color Chromaticity : | Wx:0.345; Wy:0.347 |
| White Variation : | 1.25 (Typ.)(5 points) |
| Vertical Frequency : | 60Hz |
| Reverse Scan : | Yes (180°) |
| Total Power Consumption : | 5.0W (Typ.) |
| Signal Class : | CMOS (1 ch, 6-bit) |
| Input Voltage for Panel : | 3.3/5.0V (Typ.)(VCC) |
| Input Current for Panel : | 320/200mA (Typ.)(ICC) |
| Voltage for Display Signals : | 0≤VIL≤0.3VCC; 0.7VCC≤VIH≤VCC |
Packaging & Delivery
Our company advantage in the TFT LCD Display Panel area:
1. Surface : Antiglare, Hard coating (2H)
2. Active Area : 132.48×99.36 mm (H×V)
3. Bezel Area : 135.9×102.8 mm (H×V)
4. Outline Dimension : 153×118 mm (H×V)
5. Outline Depth : 10.5±0.5 mm
6. Holes & Brackets : Side mounting holes (4-M2)
7. Landscape or Portrait : Landscape type
8. Touch Panel : Without
As one of the leading LCD distributor in China, we are strong at EOL panels and hard to find shortage panels of world famous Brand such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA HITACHI/KOE Etc.
We work closely with more than 540 enterprises in the world, including large OEM factories,franchised distributors and well-known independent distributors in LCD industry.
Details Picture for NEC NL6448BC20-18D:
